Disclaimer: SGY Love will not be responsible nor liable for any damage that might happen to your device during this process though the possibility of any damage is negligible. Try this at your own risk. This process has been tested and verified working on Samsung Galaxy Y.
Hello
Guys .. Ginawa ko ang THREAD na to para sa mga Newbie na nahihirapan
mag Flash ng Firmware ng Samsung Galaxy Y gamit ang ODIN .. Mas madali
ito Sundan kasi my mga Screenies din na nakalagay dito .. Sana ma
gustuhan nyu Have a nice day .. Happy Flashing!
How to Flash Samsung Galaxy Y via Odin
WARNING : Before Flashing Make sure na 100% or 50% ang Battery ng SGY mo .. para maiwasan masira ang SGY ..
Step 1 : Idownload
nyu muna ang mga FILES na nasa Download Link at Attachment natin .. Ang
Nasa Mediafire Link ay un ang firmware na gagamitin natin para makapag
Flash tayo gamit ang Odin at ang nasa Attachment naman ay ang ODIN3
v1.84 .. Try and Tested ko na yan
*Firmware Download Link : http://www.mediafire.com/?q31qq9op3i1u831
*Odin3 v1.84 Download Link : http://www.mediafire.com/?dxm1xlag84lpleb
Step 2 : Extract nyo sa
Desktop nyu un mga files na Dnownload nyo .. after nyo ma extract un
Firmware at Odin na download nyo .. eto ang makikita nyo
*Firmware :
*Firmware :
*Odin3 v1.84 :
Step 3 : Open nyu un Odin3
v1.84 na Dinownload nyu .. If naka windows 7 or Vista ka RUN IT AS
ADMINISTRATOR para sure .. Then my makikita kau jan na PIT at FILES
DOWNLOAD. Jan muna tau mag Focus dahil ang Dnownload natin na FIRMWARE
jan natin ilalagy .. Click nyu un Button ng PIT then Browse nyu un
folder na inextract nyu and Click nyu un file na totoro_0623.pit.
Ayan nakapag lagay kana sa PIT .. Same lang din gagawin nyu sa FILES
DOWNLOAD. Click Browse Lang .. Sundan nyu un nakalagay sa Screenies ko
PIT : totoro_0623.pit
BOOTLOADER : BOOT_S5360DDLA1_REV05.tar.md5
PDA : PDA_S5360DDLA1_REV05.tar.md5
PHONE : MODEM_S5360DDLA1_REV05.tar.md5
CSC : GT-S5360-MULTI-CSC-ODDLA1.tar.md5
Note : About RE-PARTITION .. Pwede nyu Check or Uncheck .. Uncheck if gusto normal Flashing lang .. Then Check if you want Flash repair your Brick SGY .. So far pag mag Flash ako pag my Totoro Pit Check ko parin un RE-PARTITION .. Same way Para sure But its up to you
PIT : totoro_0623.pit
BOOTLOADER : BOOT_S5360DDLA1_REV05.tar.md5
PDA : PDA_S5360DDLA1_REV05.tar.md5
PHONE : MODEM_S5360DDLA1_REV05.tar.md5
CSC : GT-S5360-MULTI-CSC-ODDLA1.tar.md5
Note : About RE-PARTITION .. Pwede nyu Check or Uncheck .. Uncheck if gusto normal Flashing lang .. Then Check if you want Flash repair your Brick SGY .. So far pag mag Flash ako pag my Totoro Pit Check ko parin un RE-PARTITION .. Same way Para sure But its up to you
Step 4 : Ayan naka-Ready na
ang Odin3 v1.84 natin .. Ngaun Turn Off nyu na ang SGY nyu .. Make sure
na walang SIM at SD Card para Maiwasan natin ang pag bura ng Important
files or Make sure You Have a Back up your Contacts and Other Files and Make sure din na naka-INSTALL na ang Driver ng SGY mo sa pc mo or my Naka-Install nang Samsung KIES na application .. If Wala pa punta kau dito Samsung.com/Kies Pag naka turn off na .. Then Press POWER BUTTON + VOLUME DOWN + HOME BUTTON Saby Saby yan huh .. After that my mag aappear sa Screen ng SGY nyu at eto un nasa Screenies natin
Sorry kung hindi malinaw pag kaka PICTURE ko sa SGY ko. Anyway after that diba yan na un lalabas .. then my mababasa kau jan na warning .. then meron jan Option na pag pipilian mo .. If VOLUME UP to CONTINUE or VOLUME DOWN to CANCEL OPERATION .. If gusto nyu ituloy Press nyu un VOLUME UP .. Then Lalabas ang Download mode Screen nyu .. Check my Screenies ulit
Ayan nasa DOWNLOAD MODE kana ..
Sorry kung hindi malinaw pag kaka PICTURE ko sa SGY ko. Anyway after that diba yan na un lalabas .. then my mababasa kau jan na warning .. then meron jan Option na pag pipilian mo .. If VOLUME UP to CONTINUE or VOLUME DOWN to CANCEL OPERATION .. If gusto nyu ituloy Press nyu un VOLUME UP .. Then Lalabas ang Download mode Screen nyu .. Check my Screenies ulit
Ayan nasa DOWNLOAD MODE kana ..
Step 5 : Ngaun Iconnect na
natin ang SGY natin na naka-DOWNLOAD MODE sa PC natin na kung saan
i-senet up natin ang Odin3 v1.84. Dapat my Colour Yellow ka makita sa
ID:COM at my nakalagy sa Message Box na Added!! Word .. It Means
nakaConnect na xa via Odin .. Like this
Step 5 : Ayan Connected na .. Before Clicking Start Button .. Check nyu muna kung tama un pag kakalagay nyu ng mga FILES DOWNLOAD .. If wala na Problem GO! Click Start Button and Wait Until it Finish! Success !! ito ang Screenies pag Ok ang pag Flash nyu via Odin
Note : After nyu makitang nag Success ang Flashing nyu wag nyu muna aalisin sa PC ang SGY nyu .. Wait nyu lang kasi mag Coconfigure na yan .. then mag rereboot ulit yan .. Wait nyu until lumabas un Boot Screen nya. Then Pwede nyu na alisin
After maging Success ang pag Flash natin Do a Hard Reset itype nyu to *2767*3855# ang Purpose nyan para fresh na Fresh ang SGY natin .. After that mag rereboot ang SGY natin Wait Until it Finish again
*TIPS and TRICKS :
Pwede rin iflash yung pda at csc lang thru odin in which case hindi na kailangan ung .pit file. Wag din lagyan ng tsek ung repartition in this case.
GOOD LUCK AND HAPPY FLASHING !!
Note : After nyu makitang nag Success ang Flashing nyu wag nyu muna aalisin sa PC ang SGY nyu .. Wait nyu lang kasi mag Coconfigure na yan .. then mag rereboot ulit yan .. Wait nyu until lumabas un Boot Screen nya. Then Pwede nyu na alisin
After maging Success ang pag Flash natin Do a Hard Reset itype nyu to *2767*3855# ang Purpose nyan para fresh na Fresh ang SGY natin .. After that mag rereboot ang SGY natin Wait Until it Finish again
*TIPS and TRICKS :
Pwede rin iflash yung pda at csc lang thru odin in which case hindi na kailangan ung .pit file. Wag din lagyan ng tsek ung repartition in this case.
GOOD LUCK AND HAPPY FLASHING !!
